| Size |
Meter size : 250×215×100(mm)
Starter size : 216×102(mm) |
| Range & error |
 0-200μg/L
± 5 %
 0.2-2.0mg/L
± 5 %
 2.0-20.0mg/L
± 0.3mg/L |
| Main technical index |
Sensitivity
: 0.5μg/L
Response
time : 90% measured value can be reached within
20 seconds |
| Working condition |
Flowing
rate : 15-25L/h
Temperature
: ≤44oC
Electrical
source : alternating current : 220V×10%; alternating
and direct current(two-way type) has its own electrical
source. |
| Installation |
Meter can be installed
on on comprehensive meter panel. It can be fixed
by thimbles on either side of meter. |
| Connection diagram |
Electrical
source,transducer wire and signal output wire are
led out separately |
Output signal |
0-5V
4-20mA
It
can output 0-2V on the clients' requirements. |
| Transducer |
Its life is more than two years under
the circumstances of dissolved oxygen. It can be
used for over three months if it is filled once. |
